Radios |
2.4 GHz 802.11b/g/n client access radio |
|
5 GHz 802.11a/n/ac client access radio |
|
2.4 GHz & 5 GHz WIDS/WIPS, spectrum analysis, and location analytics radio |
|
|
Operating bands |
2.4 GHz Bluetooth Low Energy (BLE) radio with beacon and BLE scanning support |
|
Concurrent operations of all four radios |
|
Supported frequency bands (country-specific restrictions apply): |
|
2.412-2.484 GHz |
|
5.150-5.250 GHz (UNII-1) |
|
5.250-5.350 GHZ (UNII-2) |
|
5.470-5.600, 5.660-5.725 GHz (UNII-2e) |
|
5.725 -5.825 GHz (UNII-3) |
|
|
802.11ac and 802.11n Capabilities |
2 x 2 multiple input, multiple output (MIMO) with two spatial streams |
|
SU-MIMO and MU-MIMO support |
|
Maximal ratio combining (MRC) & Beamforming |
|
20 and 40 MHz channels (802.11n), 20, 40, and 80 MHz channels (802.11ac) |
|
Up to 256 QAM on both 2.4 GHz and 5 GHz bands |
|
Packet aggregation |
|
|
Interfaces |
1x 10/100/1000 BASE-T Ethernet (RJ45) input |
|
1x Gigabet Ethernet (RJ45) with 802.3af Power over Ethernet output |
|
3x Gigabit Ethernet (RJ45) outputs |
|
|
Power |
Power over Ethernet: 37 - 57 (802.3at compatible) |
|
Power consumption: 25W max (802.3at) |
|
802.3af operating mode disables PoE out |
|
Power over Ethernet injector sold separately |
|
|
Quality of Service |
Advanced Power Save (U-APSD) |
|
WMM Access Categories with DSCP and 802.1p support |
|
Layer 7 application traffic identification and shaping |
|
|
Mobility |
PMK, OKC, and 802.11r for fast Layer 2 roaming Distributed or centralized layer 3 roaming |
|
|
LED Indicators |
4x 2 Ethernet status for Ethernet ports |
|
1 power/booting/firmware upgrade status |
|
|
Antenna |
Integrated omni-directional antennas (3.7 dBi gain at 2.4 GHz, 4.8 dBi gain at 5 GHz) |
|
|
Dimensions |
6.1” x 4.3” x 0.9” (155 mm x 110 mm x 23 mm), not including mount foot or mount plate |
|
|
Weight |
14.4 oz (409 g) |
