Cisco Meraki MR53

P/N : MR53E-HW

Name : Cisco Meraki MR53

ราคา : 42,200 บาท ( Exc. VAT )
Call Stock
  •

    Cisco Meraki MR53 Specification

  • CHASSIS :
    Access Point
  • WARRANTY :
    Smartnet RMA Only 1-Year
  • -
    2.5 Gbps dual-radio aggregate frame rate
  • -
    4 x 4 160 MHz MU-MIMO 802.11ac Wave 2
  • -
    External antenna connectors
  • -
    1x 100/1000/2.5G BASE-T Ethernet
  • -
    1x 10/100/1000 BASE-T Ethernet (RJ45)
  • -
    Power consumption: 20 W max (802.3at)
Technical Specification
Radios 2.4 GHz 802.11b/g/n/ac client access radio
  5 GHz 802.11a/n/ac Wave 2 client access radio
  2.4 GHz & 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio
  2.4 GHz Bluetoth Low Energy (BLE) radio with Beacon and BLE scanning support Concurrent operation of all three radios
  Supported frequency bands (country-specific restrictions apply):
  • 2.412-2.484 GHz
  • 5.150-5.250 GHz (UNII-1)
  • 5.250-5.350 GHz (UNII-2)
  • 5.470-5.600, 5.660-5.725 GHz (UNII-2e)
  • 5.1725-5.825 GHz (UNII-3)

802.11ac Wave 2 and 802.11n Capabilities 4 x 4 multiple input, multiple output (MIMO) with four spatial streams
  SU-MIMO and MU-MIMO support
  Maximal ratio combining (MRC) and beamforming
  20 and 40 MHz channels (802.11n), 20, 40, 80, and 160 MHz channels (802.11ac)
  Up to 256-QAM on both 2.4 GHz & 5 GHz bands
  Packet aggregation

Interfaces 1x 100/1000/2.5G BASE-T Ethernet
  1x 10/100/1000 BASE-T Ethernet (RJ45)
  1x DC power connector (5.5 mm x 2.5 mm, center positive)
  Six external RP-TNC antenna connectors

Power Power over Ethernet: 37-57 V  (802.3at required; functionality-restricted 802.3af mode supported)
  Alternative 12 V DC input
  Power consumption: 20 W max (802.3at)
  Power over Ethernet injector and DC adapter sold separately

Quality of Service Advanced Power Save (U-APSD)
  WMM Access Categories with DSCP and 802.1p support
  Layer 7 application traffic identification and shaping

Mobility PMK, OKC, and 802.11r for fast Layer 2 roaming
  Distributed or centralized Layer 3 roaming

Antenna List of compatible antennas: MA-ANT-3-A5/B5/C5/D5/E5/F5
  Individual antenna elements for each radio

Physical Security Two security screw options included
  Kensington lock hard point
  Concealed mount plate with anti-tamper cable bay

Dimensions 10.59” x 6.3” x 1.06” (269 mm x 160 mm x 27 mm), not including deskmount feet or mount plate


P/N : MR53-HW

Name : Cisco Meraki MR53

ราคา : 42,200 บาท ( Exc. VAT )
Call Stock
  •

    Cisco Meraki MR53 Specification

  • CHASSIS :
    Access Point
  • WARRANTY :
    Smartnet RMA Only 1-Year
  • -
    2.5 Gbps dual-radio aggregate frame rate
  • -
    4x4 160 MHz MU-MIMO 802.11ac Wave 2
  • -
    Integrated omni-directional antennas
  • -
    1x 100/1000/2.5G BASE-T Ethernet & 1x 10/100/1000 BASE-T Ethernet (RJ45)
  • -
    Power consumption: 21W max (802.3at)
  • -
    Bluetooth Low Energy (BLE)
