| Ports Ethernet WAN | 2 RJ-45 Gigabit Ethernet |
| Ethernet LA | 16 RJ-45 Gigabit Ethernet |
| 16 RJ-45 Gigabit Ethernet (LAN 1, 2, 3, 4 and LAN 9, 10, 11, 12 are PoE) | |
| Console | 1 RJ-45 for future use |
| USB | 2 for external 3G/4G dongle or flash drive |
| Firewall | Stateful packet inspection, 900-Mbps throughput for TCP, User Datagram Protocol (UDP) traffic |
| Web security and app visibility (licensed feature) | Dynamic web filtering: Cloud based, more than 80 categories, more than 450 million domains classified |
| Application identification: Assign policies to Internet applications Endpoint identification: Assign policies | |
| based on end device category and operating system | |
| IP Security (IPsec) | Yes (50 connections, 650 Mbps throughput) |
| IPsec site-to-site | Preconfigured profiles for Amazon Virtual Cloud and Microsoft Azure |
| Layer 2 Tunneling Protocol (L2TP) (over IPsec) | Remote access via L2TP (over IPsec for MS Windows) |
| IPsec remote access | Remote access from standard IPsec client and Cisco IPsec VPN (for example, Mac OS, Apple iOS clients) |
| VLAN | Yes (32) |
| VPN pass-through | IPsec, PPTP, L2TP |
| Port security | Yes, 802.1X |
| Quality of service (QoS) | Yes |
| IPV6 | Dual Stack, 6rd, 6in4 |
| WAN | Dynamic Host Configuration Protocol (DHCP) client, static IP, Point-to-Point Protocol over Ethernet |
| (PPPoE), PPTP, L2TP, transparent bridge | |
| Routing | Routing Information Protocol (RIP) v1 and v2, and RIP for IPv6 (RIPng) Inter-VLAN routing |
| Static routing, IGMP proxy | |
| System memory | Flash 256 MB; RAM 1 GB |
| Dimensions (W x H x D) | 280 x 44 x 170 mm (11 x 1.75 x 6.75 in) |
| Packing weight | 2390 g (5.3 lb) |
