Ports Ethernet WAN |
2 RJ-45 Gigabit Ethernet |
|
|
Ethernet LAN |
16 RJ-45 Gigabit Ethernet (LAN 1, 2, 3, 4 and LAN 9, 10, 11, 12 are PoE) |
|
PoE 802.3at, max 30W per port up to 120W total (RV345P) |
|
|
Console |
1 RJ-45 for future use |
|
|
USB |
2 for external 3G/4G dongle or flash drive |
|
|
Firewall |
Stateful packet inspection, 900-Mbps throughput for TCP, User Datagram Protocol (UDP) traffic |
|
|
Web security and app visibility (licensed feature) |
Dynamic web filtering: Cloud based, more than 80 categories, more than 450 million domains classified |
|
Application identification: Assign policies to Internet applications Endpoint identification: |
|
Assign policies based on end device category and operating system |
|
|
IP Security (IPsec) |
Yes (50 connections, 650 Mbps throughput) |
|
|
IPsec site-to-site |
Preconfigured profiles for Amazon Virtual Cloud and Microsoft Azure |
|
|
Layer 2 Tunneling Protocol (L2TP) (over IPsec) |
Remote access via L2TP (over IPsec for MS Windows) |
|
|
IPsec remote access |
Remote access from standard IPsec client and Cisco IPsec VPN (for example, Mac OS, Apple iOS clients) |
|
|
VLAN |
Yes (32) |
|
|
VPN pass-through |
IPsec, PPTP, L2TP |
|
|
Port security |
Yes, 802.1X |
|
|
Quality of service (QoS) |
Yes |
|
|
IPV6 |
Dual Stack, 6rd, 6in4 |
|
|
WAN |
Dynamic Host Configuration Protocol (DHCP) client, static IP, Point-to-Point Protocol over Ethernet |
|
(PPPoE), PPTP, L2TP, transparent bridge |
|
|
Routing |
Routing Information Protocol (RIP) v1 and v2, and RIP for IPv6 (RIPng) |
|
Inter-VLAN routing |
|
Static routing, IGMP proxy |
|
|
System memory |
Flash 256 MB; RAM 1 GB |
|
|
Dimensions (W x H x D) |
280 x 44 x 170 mm (11 x 1.75 x 6.75 in) |
|
|
Packing weight |
3200 g (7.1 lb) |
|
|
