Processor /Cache |
Up to two Intel® Xeon® processors E5-2600 v3 series with up to 18 cores each/Up to 45 MB per processor |
|
|
Memory |
Up to 1.5 TB with SK Hynix 64 GB TruDDR4 Memory LRDIMMs; System supports RDIMM/LRDIMM |
|
|
Disk Bays |
Up to 24 front and 2 rear 2.5-inch HDDs/SSDs; or up to 12 3.5-inch and 2 rear 3.5-inch HDDs + 2 rear 2.5-inch |
|
HDDs/SSDs; or up to 8 3.5-inch HDDs and 2 rear 3.5-inch or 2.5-inch HDDs/SSDs (model dependent) |
|
|
RAID Support |
12 Gbps dedicated slot for the first RAID; support for up to four RAID adapters |
|
|
Power Supply |
Up to 1/2 redundant 550 W AC, 750 W AC, 900 W AC, 1500 W AC, 900 W DC 80 PLUS® Platinum, or 750 W AC |
|
80 PLUS Titanium |
|
|
Hot-Swap Components |
Power supplies, fan modules, and HDDs/SSDs |
|
|
Network Interface |
4 x 1 GbE (std) and 1 x IMM; optional 10/40 GbE ML2 or PCIe adapter; Trusted Platform Module built-in |
|
|
Expansion Slots |
1 – 8 PCIe 3.0 slots (supports up to 2 x 300 W GPUs and up to 1 x ML2) and 1 dedicated RAID slot |
|
|
USB Ports/VGA Ports |
Up to 3 front (1 x USB 3.0, 2 x USB 2.0) and 4 back (2 x USB 3.0, 2 x USB 2.0) and 1 internal (USB 3.0) for |
|
hypervisor/1 front and 1 back |
|
|
Internal Storage |
Up to 100 TB |
|
|
Energy Efficiency |
80 PLUS® Platinum, 80 PLUS Titanium; ENERGY STAR compliance (model dependent) |
|
|
Systems Management |
IMM2.1; one IMM dedicated port and one shared; optional remote presence; Predictive Failure Analysis; LEDs; |
|
optional next-gen light path diagnostics panel |
|
|
Operating Systems (OS) Supported |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere (Optional |
|
USB Key or SD Media Adapter) |
