Cisco SF550X

P/N : SF550X-24-K9-EU

Name : Cisco SF550X

ราคา : 15,700 บาท ( Exc. VAT )
Call Stock
  •

    Cisco SF550X Specification

  • CHASSIS :
    1U Rack
  • WARRANTY :
    Lifetime Limited Warranty(5YR fr EOS)
  • -
    24 x 10/100 ports
  • -
    4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)
  • -
    Internal AC Power
  • -
    Switching capacity 84.8 Gbps
  • -
    Forwarding capacity 63.09 mpps
  • -
    Layer 2,3 Switching
Technical Specification
Layer  Layer 2, 3 Switching

Spanning Tree Protocol Standard 802.1d spanning tree support Fast convergence using 802.1w (Rapid Spanning Tree
  [RSTP]),enabled by default Multiple spanning tree instances using 802.1s (MSTP); 16 instances
  Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)

Voice VLAN Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of
  QoS. Auto voice capabilities deliver networkwide zero-touch deployment of voice endpoints and call
  control devices.

VLAN Support for up to 4094 active VLANs simultaneously; port-based and 802.1Q tag-based VLANs;
  MAC-based VLAN Management VLAN Private VLAN with promiscuous, isolated, and community port
  Guest VLAN, unauthenticated VLAN, protocol-based VLAN, IP subnet-based VLAN, CPE VLAN
  Dynamic VLAN assignment using RADIUS server along with 802.1x client authentication

DHCP relay at Layer 2 Relay of DHCP traffic to DHCP server in a different VLAN. Works with DHCP option 82.

IGMP (versions 1, 2, and 3) snooping Internet Group Management Protocol (IGMP) limits bandwidth-intensive multicast traffic to only the
  equesters; supports 4K multicast groups (source-specific multicasting is also supported).

IGMP querier IGMP querier is used to support a Layer 2 multicast domain of snooping switches in the absence
  of a multicast router.

IPv4 routing Wirespeed routing of IPv4 packets, Up to 7K routes and up to 256 IP interfaces

Wirespeed IPv6 static routing Up to 7K routes and up to 256 IPv6 interfaces

Layer 3 interface Configuration of Layer 3 interface on physical port, LAG, VLAN interface, or loopback interface

CIDR Support for classless interdomain routing

RIP v2 Support for Routing Information Protocol version 2 for dynamic routing

VRRP Virtual Router Redundancy Protocol (VRRP) delivers improved availability in a Layer 3 network by
  providing redundancy of the default gateway servicing hosts on the network. VRRP versions 2 and 3 are
  supported. Up to 255 virtual routers are supported

DHCP server Switch functions as an IPv4 DHCP server serving IP addresses for multiple DHCP pools/scopes.
  Support for DHCP options

DHCP relay at Layer 3 Relay of DHCP traffic across IP domains

Console port  Cisco Standard RJ45 console port

USB slot USB Type-A slot on the front panel of the switch for easy file and image management

Buttons Reset button

LEDs System, master, fan, RPS, stack ID, link/speed per port

Power 100 - 240V 47 - 63 Hz, internal, universal


P/N : SF550X-48-K9-EU

Name : Cisco SF550X

ราคา : 24,300 บาท ( Exc. VAT )
Call Stock
  •

    Cisco SF550X Specification

  • CHASSIS :
    1U Rack
  • WARRANTY :
    Lifetime Limited Warranty(5YR fr EOS)
  • -
    48 x 10/100 ports
  • -
    4 x 10 Gigabit Ethernet (2 x 10GBase-T/SFP+ combo + 2 x SFP+)
  • -
    Internal AC Power
  • -
    Switching capacity 89.6 Gbps
  • -
    Forwarding capacity 66.66 mpps
  • -
    Layer 2 Switching
