Model Name |
TS-EC1280U-E3-4GE-R2 |
TS-EC1280U-i3-4GE-R2 |
TS-EC1280U-i3-8G-R2 |
CPU |
TS-EC1280U-E3-4GE-R2: Intel® Xeon® E3-1246 v3 Quad-core processor |
TS-EC1280U-i3-4GE-R2: Intel ® Core i3-4150 processor |
TS-EC1280U-i3-8G-R2:Intel® Core i3-4150 processor |
Memory |
Total memory slots: 4 |
TS-EC1280U-E3-4GE-R2/ TS-EC1280U-i3-4GE-R2: |
System memory: 4 GB DDR3 ECC RAM |
Memory module pre-installed: 2 GB x2 |
Memory expandable up to: 32 GB (8GB x4) |
TS-EC1280U-i3-8G-R2: |
System memory: 8 GB DDR3 non-ECC RAM |
Memory module pre-installed: 4 GB x2 |
Memory expandable up to: 32 GB (8GB x4) |
Note: |
1. When upgrading RAM to more than 28GB, the original 4GB RAM modules must be removed. |
2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
Flash Memory |
512MB DOM |
Internal Cache Port |
Two mSATA port on board for read caching |
Note: The standard system is shipped without mSATA flash. For the optional mSATA flash, please visit |
Hard Drive |
12 x 3.5-inch SATA 6Gbps/3Gbps hard drive or 2.5-inch SATA, 6Gbps/3Gbps hard drive SSD hard drive |
NOTE: |
1. The standard system is shipped without hard drives. |
2. For the hard drive compatibility list, please visit Compatibility list |
Hard Drive Tray |
12 x hot-swappable and lockable tray |
LAN Port |
Built-in 2 x 10 GbE SFP+ ports (LAN-10G2SF-MLX) and 4 x GbE ports |
40GbE is optional |
Note: |
1. For the optional network card compatibility list, please visit Compatibility list of Expansion Card |
2. For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual. |
LED Indicators |
Status, 10 GbE, LAN, eSATA, storage expansion port status |
USB |
4x USB 3.0 port (rear) |
4x USB 2.0 port (rear) |
Support USB printer, pen drive, USB hub, and USB UPS etc. |
Buttons |
System: Power button and reset button |
Alarm Buzzer |
System warning |
Form Factor |
2U, Rackmount |
Dimensions |
88(H) x 442.5(W) x 530.5(D) mm |
3.46(H) x 17.42(W) x 20.89(D) inch |
Weight |
Net weight (NAS only) : 14.18 kg/ 31.26 lb |
Gross weight (with packing and accessories) : 21.41 kg/ 47.20 lb |
Power Consumption (W) |
Sleep mode: 80.41 |
In Operation: 166.58 W |
(with 12 x 1TB hard drive installed) |
Sound Level |
Sound pressure (LpAm) :55.3 dB(A) |
Temperature |
0-40˚C |
Relative Humidity |
5~95% non-condensing, wet bulb: 27˚C. |
Power Supply |
Redundant power: |
Input: 47-63 Hz; 100-127V~/ 8A; 200-240V/ 4A |
Output: 400W |
PCIe Slot |
2 (Right slot: 1* PCIe Gen3 x8; Left slot: 1* PCIe Gen3 x4) |
Note: |
The PCIe Gen3 x8 slot is occupied by a 10GbE network adapter. |
Fan |
4 x 6 cm smart cooling fan |
