FortiAP 25D

P/N : FAP-25D-S

Name : FortiAP 25D

ราคา : 0 บาท ( Exc. VAT )
End of Sale
  •

    FortiAP 25D Specification

  • CHASSIS :
    Desktop, Wall
  • WARRANTY :
    1Yr 1St Time FortiCare FAP25D
  • -
    Suggested Use Case : Low density indoor
  • -
    IEEE Standard : 802.11a, 802.11b, 802.11e
  • -
    Number of Radio : 1
  • -
    MIMO : 2x2 MIMO 2 spatial stream
  • -
    Simultaneous SSIDs :8 (7 if background scanning enabled)
  • -
    Ethernet Port : 1x GE RJ45 WAN port, 4x FE RJ45 LAN ports
Technical Specification
Suggested Use Case FORTIAP 25D
Hardware
Hardware Type Remote (Indoor)
Number of Antennas 1
Number of Antennas 2 internal
Peak Antenna Gain 2 dBi for 2.4 GHz, 3 dBi for 5 GHz
Frequency Bands (GHz) 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850
Frequency of Radio 1 2.4 GHz b/g/n, 5 GHz a/n
Throughput Up to 300 Mbps
Tx/Rx Streams 2x2 MIMO 2 spatial stream
Ethernet Ports 1x GE RJ45 WAN port, 4x FE RJ45 LAN ports
WME Multimedia Extensions Yes (4 priority queues for voice, video, data and background traffic
Simultaneous SSIDs 8 (7 if background scanning enabled)
EAP Type(s) EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST
User/Device Authentication WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist
Maximum Tx Power 16 dBm (40 mW
Mean Time Between Failures >10 years
IEEE Specifications 802.11a, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x
802.11n Features 20 MHz and 40 MHz HighThroughput (HT) Support
  ncreased maximum frame transmission by incorporating A-MPDU and A-MSDU Packet Aggregation
  Conserve power via Dynamic MIMO power save
Advanced 802.11n to enhance rate-over-range including: Low-density parity check (LDPC) encoding
  Maximum likelihood demodulation (MLD)
  Transmit beamforming (TxBF)
  Maximum Ratio Combining (MRC) for improved receiver
Mounting Options Desktop, Wall
Included Accessories AC power adapter and wall mount kit
FortiPresence Capable Yes
Wireless Monitoring Capabilities
Frequencies scanned 2.4 and 5 GHz
Full-time scan as dedicated monitor Yes
Dimensions
Length x Width x Height 0.9 x 2.8 x 1.4 inches (2.28 x 7 x 3.5 cm)
Weight 0.62 lbs (0.28 kg)
Package (shipping) Weight 1.01 lbs (0.46 kg)
Environment
Power Supply Adapter Input: 100–240V AC, 50–60 Hz
Power Consumption (Average) 2.5 W
Power Consumption (Maximum) 2.7 W
Humidity 0–90% non-condensing
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -13–158°F (-25–70°C)
Directives Low Voltage Directive • RoHS
Certifications
WiFi Alliance Certified No
Warranty
Limited Lifetime Warranty Yes
