Cisco SF220 POE

P/N : SF220-24P-K9-EU

Name : Cisco SF220 POE

ราคา : 11,600 บาท ( Exc. VAT )
Call Stock
  •

    Cisco SF220 POE Specification

  • CHASSIS :
    1U Rack 440 x 44 x 250
  • WARRANTY :
    Lifetime Limited warranty (5YR fr EOS)
  • -
    24 Fast Ethernet
  • -
    2x Combo Ports (RJ-45 + SFP) Gigabit Ethernet
  • -
    Switching capacity : 8.8 Gbps
  • -
    Forwarding capacity : 6.55 mpps
  • -
    Layer 2 Switching + POE 180W/24 Ports
  • -
    Web & Command Line Management
Technical Specification
รายละเอียดสินค้า (Specification) :  Cisco SF220-24 Smart Plus Switch
Part Number :  SF220-24-K9-EU
Port 10/100 (RJ-45) :  24 10/100 ports
Combo Ports (RJ-45 + SFP) :  2 Gigabit RJ45/SFP combo port
Forwarding rate :  6.55Mpps (64-byte packets)
Switch Capacity :  8.8Gbps
Layer 2 Switching :
MAC Table :  8192 MAC addresses
Spanning Tree Protocol (STP) :  - Standard 802.1d Spanning Tree support, enabled by default
  - Fast convergence using 802.1w (Rapid Spanning Tree [RSTP])
  - Multiple Spanning Tree instances using 802.1s (MSTP)
  - 16 instances are supported
Port grouping :  Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)
VLAN :  - Support for up to 256 VLANs simultaneously
  - Port-based and 802.1Q tag-based VLANs
  - Management VLAN
  - Guest VLAN
Auto Voice VLAN :  Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS
Switch Management :
Web User Interface :  Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS). Supports configuration, system dashboard, system maintenance, and monitoring
Text-Editable Config Files :  Config files can be edited with a text editor and downloaded to another switch, facilitating easier mass deployment
Command line interface :  Scriptable CLI; a full CLI is supported. User privilege levels 1 and 15 are supported for the CLI
Cloud Services :  Support for Cisco Small Business FindIT Network Tool
SNMP SNMP :  versions 1, 2c, and 3 with support for traps, and SNMP version 3 user-based security model (USM)
Warranty :  5YR fr EOS คือ รับประกันจนกว่า Cisco ประกาศเลิกจำหน่าย จะรับประกันต่อให้อีกไม่เกิน 5 ปี

P/N : SF220-48P-K9-EU

Name : Cisco SF220 POE

ราคา : 21,800 บาท ( Exc. VAT )
Call Stock
  •

    Cisco SF220 POE Specification

  • CHASSIS :
    1U Rack 440 x 44 x 350
  • WARRANTY :
    Lifetime Limited warranty (5YR fr EOS)
  • -
    48 Fast Ethernet
  • -
    2x Combo Ports (RJ-45 + SFP) Gigabit Ethernet
  • -
    Switching capacity : 13.6 Gbps
  • -
    Forwarding capacity : 10.12 mpps
  • -
    Layer 2 Switching + POE 375W/48 Ports
  • -
    Web & Command Line Management
