| Standards | IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T |
| Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet | |
| Cabling type | Category 5e or better |
| LED indicators | System/PWR, link/activity, 100M*, cable diagnostics, loop detection, gigabit,* mini-GBIC* *if present |
| Ports | 10/100/1000 Ethernet, power port for AC adapter or power cord |
| Power supply | SF95D-05, SF95D-08: DC 12V, 500mA |
| SF95D-16, SG95D-08, SG95D-05: DC 12V, 1.0A | |
| SF95-24, SG95-16, SG95-24: 110-240VAC, 50-60 Hz, internal, universal | |
| Lock slot | Slot for Kensington lock |
| Fan/fanless models | All models have no fans and are fanless |
| Switching capacity | SG95D-05: 10 Gbps |
| SG95D-08: 16 Gbps | |
| SG95-16: 32 Gbps | |
| SG95-24: 48 Gbps | |
| Forwarding capacity | SG95D-05: 7.4 mpps |
| SG95D-08: 11.9 mpps | |
| SG95-16: 23.8 mpps | |
| SG95-24: 35.7 mpps | |
| dimensions (W x D x H) | SG95D-05: 110x30x100 mm |
| SG95D-08: 160x30x103.5 mm | |
| SG95-16: 279.4 x 26 x 110 mm | |
| SG95-24: 279.4x44.45x170mm | |
| Weight | SG95D-05: 0.70 lb. (0.32 kg) |
| SG95D-08: 0.94 lb. (0.43 kg) | |
| SG95-16: 3.15 lb. (2.13 kg) | |
| SG95-24: 3.59 lb. (1.63 kg) | |
